The Medical Waste Disinfection Vehicle (LiYing MDV) is a mobile sterilisation station on a truck with an improved internal layout designed for mobile requirements. It adapts to various emergencies and support needs. Solid and efficient, and we have upgraded it for many generations to cope with the various situations and cases, so please contact us about detail.
Specifications:
The Medical Waste Disposal Vehicle (LiYing MDV series) is a mobile sterilization station on a truck with an improved internal layout designed for mobile requirements. It adapts to various emergencies and support needs. Solid and efficient, and we have upgraded it for many generations to cope with the hundreds of various situations and cases we meet, so please contact us about detail. 📲
The convenience and flexibility of the mobile medical waste microwave sterilization vehicle make it a good service for various emergencies, which is plug and play, convenient and fast. It usualy well service for nature disasters like sudden epidemics and remote areas, and also military field hospital, marine and island medical waste disposal, etc.
The Medical waste Disposal Vehicle series treatment capaticy varies from 60kg/h to 300kg/h.
*Click below to watch the MDV video
| LYC-5150 | LYC-5180 | ||
| Model No. | LYC5150XXDF6 | LYC5180XXDS6 | |
| Dimensions (L*W*H) | 9780*2550*3990mm | 10150*2550*3990mm | |
| Overall weight | 15,000kg | 18,000kg | |
| Height when flap open | 6,500mm | 6,500mm | |
| Vehicle mounted generator | - | 150kw | |
| Installed Power | 120kw (72kw steam generator included) | 120kw (72kw steam generator included) | |
| Treatment capacity (medical waste density average 0.1kg/l~0.15kg/l) | 300kg/h (±10%) | 300kg/h (±10%) | |
| Operation and control | PLC control, automatic process | ||
| Shredding system | Two-shaft shredder, automatic reverse system is configured to avoid material blockage. | ||
| Feeding form | Automatic lifting and charging system contained | ||
| Sterilization temperature | ≥95℃ | ||
| Sterilization duration | ≥45min | ||
| Sterilization effect | ≥6 log10 (99.9999%) The treatment effect test uses Bacillus subtilis var. niger spore (ATCC 9372) as biological indicator, with killing logarithm value ≥ 6.00. | ||
| Microwave frequency | 2450MHz (±50MHz) | ||
| Microwave generator power | 1.25KW * 10unit | ||
| Disposal Staffing needs | Non specialized operator : 2 | ||
①Infectious waste is temporarily held in a waste container(s) and then emptied into a pre-storage hopper via a loading system located at the rear of the MDV.
②The infectious waste is fed into the shredding system by a feed arm where it is shredded.
③The shredded material is conveyed through a microwave section and temperature holding section, respectively for sterilization, with microwave of 2450MHz (±50MHz), temperature ≥95℃, with over 45minutes.
④The sterilized and unrecognizable (sharps) waste is then discharged into large waste containers (or compaction units) by the discharging screw conveyor.
⑤From there the material can be transported to a local municipal landfill for disposal or to a refuse recycling plant.
⚫What does the Microwave Disposal Unit for Medical Waste do to bacteria?
Microwave sterilization is the result of microwave thermal effect and biological effect, which can make microwave energy and bacteria directly interact, rapid sterilization.
The thermal effect of microwave energy: Under certain intensity microwave field, the bacteria will be due to the absorption of polarized molecules can increase the temperature of microwave, so that the protein deformation, loss of biological activity. The thermal effect of microwave mainly plays the role of rapid temperature sterilization.
Non-thermal effects of microwave energy: High-frequency electric fields change the polarized molecular structure, resulting in the loss of vitality or death of proteins and physiologically active substances in the microbes, and the special effects of conventional physical sterilization in the sterilization
MDU series products are designed as an automatic operation system with minimal operator operations, with the following characteristics:
Microwave heating is uniform, no energy loss, high energy, strong penetration into the object, instantaneous penetration into the object, good energy-saving effect, take the model with a daily processing capacity of 5T/d as an example, installed power Only 117 kilowatts.
The temperature of action is low, and the heat loss is slow: If microwave and ordinary heating produce the same amount of sterilization, the temperature of the object will be significantly lower than that of ordinary heating. The waste after microwave sterilization is non-toxic, without residue, and lightly damaged.
Microwave can effectively sterilize all materials on all organisms with no select. It has a broad spectrum of sterilization bacteria and can kill various microorganisms and pathogens.
Microwave sterilization requires a small working environment and small area, does not cause high temperature to the surrounding environment, and is clean and hygienic.
No acid gas and dioxins and other pollutants are produced.
Integrated equipment design, convenient and fast, with low operation noise.
The equipment has a high degree of automation, and only one person is required to operate a complete set of equipment, saving labor costs.
Low energy consumption, the whole set of equipment only needs only electric drive.
The medical waste treatment method is flexible. When there is medical waste to be processed at any time, the equipment can be turned off after the treatment is completed, which minimizes energy loss and personnel wages and saves treatment costs.
The convenience and flexibility of the mobile medical waste microwave sterilization vehicle make it a good service for various emergencies.
For areas with vast land and sparsely populated areas where the amount of medical waste generated is small, one vehicle can serve multiple areas.
| Compare technologies | LiYing Tech | Autoclave | Incinerator |
|---|---|---|---|
| (Microwave) | (Hot steam) | (Incineration) | |
| Process | Continuous/Batch | Batch | Continuous/Batch |
| Integral shredding | ✓ | X | X |
| Waste volume reduced | ✓ | ✓ | ✓ |
| Installation requirements | Low | High | Very High |
| On-site installable | ✓ | ✓ | X |
| Odor | Low | High | High |
| Noise | Low | High | High |
| Sterilization effect | High | High | High |
| Cost | |||
| Labor costs | Low | High | High |
| Investment costs | Intermediate | Intermediate | High |
| Energy Used | Very Low | High | High |
| Maintenance costs | Low | High | High |
| ROI | High | Low | Low |
| Features | |||
| Environmental Impact | Eco-friendly | Intermediate | Significant |
| Safety | High | Pressure risk | Low |
| Ease of Operation | One-man Operation | Low | Low |
